The patent battle between Shenzhenshi Leiming Shangmaozhongxin and Novoluto GmbH puts patent US9763851B2 under scrutiny. This patent claims a groundbreaking stimulation device designed for erogenous zones, offering a pressure-based experience without direct skin contact.
Marketed as an innovation that reduces irritation and enhances hygiene, this technology has been a key player in its industry. But does it truly stand on new ground, or is there prior art that could shake its foundation? If earlier patents disclose similar pressure-based stimulation mechanisms, Novoluto’s claims could be at risk.
That is where Global Patent Search (GPS) comes in, helping uncover potential prior art that could challenge the validity of US9763851B2. Let us break down this patent’s core features before diving into the prior art that could put it to the test.
Understanding Patent US9763851B2
Patent US9763851B2, owned by Novoluto GmbH, describes a stimulation device for erogenous zones, specifically designed to create a pressure field that stimulates the clitoris without direct contact.
Unlike traditional vibratory stimulators, which rely on direct skin contact, this device uses alternating pressure waves to generate a massage-like effect, enhancing pleasure while reducing skin irritation and hygiene concerns.
Source: US9763851B2
Its four key features are:
#1. Pressure field generator – Uses at least two chambers to create alternating positive and negative pressures, simulating natural stimulation.
#2. Connection element – Links the two chambers, directing airflow to the erogenous zone without direct touch.
#3. Drive unit & control device – Controls the pressure field’s intensity and pattern, allowing for customizable stimulation.
#4. Hygienic, non-contact stimulation – Reduces the risk of irritation, habituation effects, and hygiene concerns found in traditional suction-based stimulators.
Novoluto GmbH’s US9763851B2 is at the center of litigation, with Shenzhenshi Leiming Shangmaozhongxin potentially challenging its validity. If prior patents disclose similar pressure-based stimulation technology, Novoluto’s claims could face scrutiny. Finding strong prior art could impact this case significantly.
Potential Prior Art References for US9763851B2
#1. CN105579017B
This patent, filed on July 22, 2014, describes a stimulation device for the clitoris using a pressure field generator with at least two chambers. The first chamber changes volume to generate alternating positive and negative pressures, stimulating the clitoris without direct contact. The device also features a drive unit, a connection element, and a control system, ensuring precise pressure modulation for enhanced stimulation.
Why this qualifies as Potential Prior Art?
- Pressure field generator with first chamber – The reference describes a stimulation device using a pressure-based mechanism with a first chamber.
- Drive unit for volume modulation – It includes a drive unit that alters the first chamber’s volume to generate a pressure field.
- Valve-free operation – The device operates without valves, reducing complexity and hygiene concerns.
- Portable and battery-powered – The reference explicitly mentions a compact, battery-powered design for convenience.
Which features of US9763851B2 are disclosed by CN105579017B?
| Key Feature of Claim 1 | Disclosure Status |
| A stimulation device for a clitoris uses a pressure field generator with a first chamber having a single opening | Fully Disclosed |
| A second chamber has first and second openings, with the second opening meant for placing over the clitoris | Partially Disclosed |
| A straight channel connection element with first and second openings connects the first chamber’s opening to the first opening of the second chamber | Partially Disclosed |
| A drive unit changes the volume of the first chamber to generate a stimulating pressure field in the second chamber | Fully Disclosed |
| The pressure field consists of negative and positive pressures modulated relative to a reference pressure | Fully Disclosed |
| The first chamber connects to the second chamber only through the connection element | Fully Disclosed |
| The device operates without any valves | Fully Disclosed |
| The device is portable and battery-powered | Fully Disclosed |
| The rigid connection element’s aligned openings create a nozzle effect directing media flow toward the clitoris | Fully Disclosed |
| The second opening of the connection element faces the clitoris through the second chamber | Fully Disclosed |
Key Excerpt from CN105579017B:
“The pressure field generator in the stimulation device has at least one first chamber, at least one second chamber with at least one opening for placement on a body part, and a connection element linking them. The drive unit modifies the first chamber’s volume to generate a pulsating pressure field for stimulation.”
#2. US5593381A
This patent, filed on July 25, 1994, discloses a skin and tissue stimulation device designed for medical and cosmetic treatments. It features a DC motor and solenoid system that controls an applicator’s vertical and horizontal movements to manipulate the skin. The device is portable and electronically controlled, allowing precise adjustments in stimulation intensity.
Source: GPS
Why this qualifies as Potential Prior Art?
- Motor-driven stimulation – The device includes a DC motor and solenoid system that generates movement for skin treatment.
- Electronic control system – A circuit-based control system regulates the frequency and intensity of stimulation.
- Portable design – The device is compact and handheld, allowing for ease of use.
- Partial mention of battery power – The reference suggests portability, but does not explicitly state battery operation.
Which features of US9763851B2 are disclosed by US5593381A?
| Key Feature of Claim 1 | Disclosure Status |
| The device is portable and battery-powered | Partially Disclosed |
Key Excerpt from US5593381A:
“The preferred embodiment includes a compact, portable housing with a reversible motor and solenoid for providing an applicator with horizontal and vertical movements to manipulate the skin and underlying tissue under electronic control.”
#3. US9017273B2
This patent, filed on March 2, 2009, describes a system for generating counter-stimulation to treat Restless Leg Syndrome (RLS). The device delivers low-amplitude, timed stimulation through a controller-driven unit that sits adjacent to the patient’s body. The counter-stimulation is designed to be strong enough to relieve symptoms but weak enough to avoid waking the patient.
Why this qualifies as Potential Prior Art?
- Counter-stimulation technology – The device generates controlled stimulation to relieve symptoms of Restless Leg Syndrome.
- Electronic control system – A controller communicates with the stimulation unit to regulate amplitude, intensity, and duration.
- Portable design – The device is compact and can be worn on the body for extended periods.
- Partial mention of battery power – While it is portable, the reference does not explicitly confirm battery operation.
Which Features of US9763851B2 Are Disclosed by US9017273B2?
| Key Feature of Claim 1 | Disclosure Status |
| The device is portable and battery-powered | Partially Disclosed |
Key Excerpt from US9017273B2:
“A system for generating a counter-stimulation in a patient suffering from RLS comprises a device configured to generate a counter-stimulation with an amplitude, intensity, and duration designed to relieve RLS symptoms while allowing the patient to remain asleep.”
#4. KR200411400Y1
This patent, filed on Jan. 3, 2006, describes a low-frequency electrical stimulator that uses electrical impulses to relieve pain and treat diseases. The device is designed for wearable application and can be controlled via a remote unit. It features battery operation, an output terminal for stimulation, and adjustable intensity modes.
Why this qualifies as Potential Prior Art?
- Wearable electrical stimulation – The device is worn on the body and delivers stimulation through electrical impulses.
- Battery-powered design – The device operates portably using a built-in battery.
- Remote-controlled operation – A wireless remote unit controls the stimulation settings.
- Adjustable stimulation modes – Users can adjust intensity, frequency, and type of stimulation.
Here’s what the mapping from the tool for this particular patent looks like:
Source: GPS
Which features of US9763851B2 are disclosed by KR200411400Y1?
| Key Feature of Claim 1 | Disclosure Status |
|---|---|
| The device is portable and battery-powered | Fully Disclosed |
Key Excerpt from KR200411400Y1:
“The device comprises a case containing a battery, a magnetic pole unit, and an output terminal for providing electrical stimulation. It can be worn on the arms, legs, or other body parts and controlled via a remote system.”
#5. KR101075943B1
This patent, filed on Oct. 6, 2009, describes a tactile stimulator that uses vibration motors to provide sensory stimulation. The device is battery-powered, portable, and features a power supply unit, controller, and booster circuit to regulate voltage. Unlike pressure-based devices, this stimulator focuses on vibrational feedback rather than air pressure manipulation.
Why this qualifies as Potential Prior Art?
- Battery-powered operation – The device runs on alkaline or rechargeable batteries.
- Portable design – Small and designed for easy use on different body parts.
- No valve-based components – The system operates without mechanical valves.
- Electronic control – Features a controller, status indicator, and switch mechanism.
Which Features of US9763851B2 Are Disclosed by KR101075943B1?
| Key Feature of Claim 1 | Disclosure Status |
| The device operates without any valves | Fully Disclosed |
| The device is portable and battery-powered | Fully Disclosed |
Key Excerpt from KR101075943B1:
“The device includes a power supply unit with a battery, a switch for controlling power, and a booster circuit to regulate voltage. It is a fully portable, battery-operated tactile stimulator with no need for mechanical valves.”
Feature Comparison Table
| Key Feature of Claim 1 | CN105579017B | US5593381A | US9017273B2 | KR200411400Y1 | KR101075943B1 |
| A pressure field generator has a first chamber with a single opening | Full | None | None | None | None |
| A pressure field generator has a second chamber with first and second openings | Partial | None | None | None | None |
| The second opening of the second chamber is for placing over the clitoris | Partial | None | None | None | None |
| A rigid connection element with first and second openings forms a straight channel connecting the first chamber’s opening with the second chamber’s first opening | Partial | None | None | None | None |
| A drive unit changes the first chamber’s volume to generate a stimulating pressure field in the second chamber | Full | None | None | None | None |
| The pressure field consists of negative and positive pressures modulated with respect to a reference pressure | Full | None | None | None | None |
| The first chamber connects to the second chamber solely through the connection element | Full | None | None | None | None |
| The device operates without any valves | Full | None | None | None | Full |
| The device is portable and battery-powered | Full | Partial | Partial | Full | Full |
| The connection element’s aligned openings create a nozzle effect directing media flow toward the clitoris | Full | None | None | None | None |
| The connection element’s second opening faces the clitoris through the second chamber | Full | None | None | None | None |
How to Find Prior Art Using Global Patent Search
Identifying strong prior art is essential for evaluating a patent’s validity. The Global Patent Search (GPS) tool streamlines this process with advanced search capabilities and precise feature mapping. With this tool, you can:
Search by Patent number or description: Instantly retrieve relevant prior art references.
Source: GPS
Leverage feature mapping: Compare key features against existing patents for a detailed analysis.
Review matching results: Access a curated list of potential prior art references ranked by relevance.
Analyze detailed reports: Examine how each reference aligns with the patent claims in question.
Make data-backed decisions: Strengthen your case with verified, structured insights.
Using Global Patent Search, you can eliminate uncertainty and conduct efficient, thorough prior art research, giving you the confidence to navigate patent disputes effectively.
